GPOWER Inverters ( 6 KW IP21 )

Description

⚙️ GPower 6KW Inverter Specifications

• Maximum PV Input Current: 27A

• Charging: User-adjustable charging current and voltage

• Monitoring: Real-time status display and control via monitoring software

• Load Management: Dual outputs for smart load management

• Programmable Modes: Grid-Tie, Off-Grid, and Grid-Tie with Backup

• Parallel Operation: Supports up to 9 units in parallel

🔌 GPower S Series Off-Grid Inverter Features

• Models Available:

  • S-1500-24: 1500W, 24V battery system

  • S-3000-24: 3000W, 24V battery system

  • S-5000-48: 5000W, 48V battery system

• Surge Power: Up to 10,000VA for the S-5000-48 model

• MPPT Solar Charger: Built-in with a range of 120–380 VDC

• Maximum PV Array Power: Up to 5000W

• Maximum PV Open Circuit Voltage: 400 VDC

• Maximum Solar Charge Current: 60A

• Maximum AC Charge Current: 40A

• Communication Interfaces: USB, RS232, RS485, Bluetooth, Dry-contact

• Operating Temperature Range: -10℃ to 50℃

• Humidity Tolerance: 5% to 95% Relative Humidity (Non-condensing).
