SOLIS ( HYBRID ) 20 KW
🔑 Key Features
- Hybrid Operation
- Advanced MPPT Technology
- Pure Sine Wave Output
- Built-in Monitoring Interfaces
- Robust & Durable Design
Description
The Solis S6-EH3P20K-H 20kW Three-Phase Hybrid Inverter is a reliable and efficient energy solution, ideal for enhancing the performance and reliability of your solar power system. Its hybrid functionality, robust protection features, and smart monitoring capabilities make it a valuable addition to any solar installation.
If you need further assistance in selecting compatible batteries or have questions about installation and compatibility, feel free to ask!
🔧 Key Specifications
-
Rated AC Output Power: 20,000 W
-
Maximum PV Input Power: 32,000 W
-
MPPT Voltage Range: 200–850 V
-
Number of MPPT Trackers: 4
-
Maximum Input Voltage: 1,000 V
-
Maximum DC Input Current: 96 A
-
Battery Voltage Range: 40–60 V (48V nominal)
-
Maximum Charge/Discharge Current: 190 A
-
Surge Power Backup: 200% for 10 seconds
-
Efficiency: Up to 98.5%
-
Protection Rating: IP65 (suitable for outdoor installations)
-
Dimensions: Approximately 530 mm × 700 mm × 356.5 mm
-
Weight: Approximately 58.2 kg
-
Operating Temperature Range: -40°C to +60°C
-
Communication Interfaces: RS485, CAN, optional Wi-Fi, GPRS, LAN
